Split Guard Rails:
- Four polypropylene guard rails provide patient protection
- Two additional side rails near the footboard enhance safety and support for patients while standing.
- Displays the angle of the backrest, lateral tilt, and Trendelenburg/Reverse Trendelenburg positions. Integrated Scale Control Panel:
- Located at the foot end and designed to withstand impacts.
- Made of PP plastic, easily removable for sterilization.
- PF backrest allows for X-ray imaging.
- Includes 150 mm noiseless castors with central locking.
- Located on both sides of the guard rails.
- Positioned at the bottom of the foot end.
- Prevent accidental removal of the head and foot boards during transport.
- Sliding design allows for cassette insertion beneath the mattress platform from the side.
- Electric CPR can be operated with a single key control.
- Manual CPR features a damping device for safe, gradual lowering of the backrest during power failure.
- Power Supply: 220V/110V, 50Hz/60Hz
- Maximum Input: 1.6A, 450VA
- Water and Dust Protection: IPX4
- Equipment Security Classification: Class II
- Electrical Injury Protection Level: Applied part type BF
- Electric Motor Operation Mode: 10% load factor, max. 2 minutes on/18 minutes off
- Seven Outer Dimensions (with side rails up): L2240 x W1060 mm (±10 mm)
- Mattress Platform Dimensions: L1965 x W920 mm (±10 mm)
- Bed Height: H530-930 mm (±10 mm)
- Bed Extension: 200 mm (±10 mm)
- Backrest: ≥70°
- Thigh Rest: ≥30°
- Trendelenburg/Reverse Trendelenburg: ≥12°
- Left and Right Tilt: ≥15°
- Height of Side Rails (above mattress platform): 440 mm (±10 mm)
- Safe Working Load: 200 kg
- Weighing System: Yes
